Ebara DWF Submersible Pumps With Channel Impeller

FREE DELIVERY

2 Year Guarantee

Best Price Guarantee

Free Expert Advice

Money Back Guarantee

Ebara DWF submersible pumps are used as wastewater pumps that can handle solids up to 50mm. Suitable for various applications, including remote sewage stations for housing developments, agricultural waste, pubs, hotels, restaurants and water displays, these submersible pumps can be used in fixed and mobile installations.

Starting at £548.16 £456.80

Grouped product items
Model	Voltage	Power	Outlet	Max. Flow	Max. Head	Float Switch	SKU	RRP	Our Price (ex VAT)
Model: DWF M 75	Voltage: 230V	Power: 0.55 kW	Outlet: DN50	Maxflow: 500 l/min	Maxhead: 11 m	Floatswitch: NO	SKU: 110-052	RRP: £1,071.00	Our Price: £899.64 £749.70
Model: DWF M 75 A	Voltage: 230V	Power: 0.55 kW	Outlet: DN50	Maxflow: 500 l/min	Maxhead: 11 m	Floatswitch: YES	SKU: 110-053	RRP: £1,107.00	Our Price: £929.88 £774.90
Model: DWF M 100	Voltage: 230V	Power: 0.75 kW	Outlet: DN50	Maxflow: 600 l/min	Maxhead: 13 m	Floatswitch: NO	SKU: 110-056	RRP: £1,130.00	Our Price: £949.20 £791.00
Model: DWF M 100 A	Voltage: 230V	Power: 0.75 kW	Outlet: DN50	Maxflow: 600 l/min	Maxhead: 13 m	Floatswitch: YES	SKU: 110-057	RRP: £1,271.00	Our Price: £1,067.64 £889.70
Model: DWF M 150	Voltage: 230V	Power: 1.10 kW	Outlet: DN50	Maxflow: 700 l/min	Maxhead: 15 m	Floatswitch: NO	SKU: 110-060	RRP: £1,456.00	Our Price: £1,223.04 £1,019.20
Model: DWF M 150 A	Voltage: 230V	Power: 1.10 kW	Outlet: DN50	Maxflow: 700 l/min	Maxhead: 15 m	Floatswitch: YES	SKU: 110-061	RRP: £1,507.00	Our Price: £1,265.88 £1,054.90
Model: DWF 75	Voltage: 400V	Power: 0.55 kW	Outlet: DN50	Maxflow: 500 l/min	Maxhead: 11 m	Floatswitch: NO	SKU: 110-064	RRP: £1,071.00	Our Price: £899.64 £749.70
Model: DWF 100	Voltage: 400V	Power: 0.75 kW	Outlet: DN50	Maxflow: 600 l/min	Maxhead: 13 m	Floatswitch: NO	SKU: 110-066	RRP: £1,130.00	Our Price: £949.20 £791.00
Model: DWF 150	Voltage: 400V	Power: 1.10 kW	Outlet: DN50	Maxflow: 700 l/min	Maxhead: 15 m	Floatswitch: NO	SKU: 110-068	RRP: £1,456.00	Our Price: £1,223.04 £1,019.20
Model: DWF 200	Voltage: 400V	Power: 1.50 kW	Outlet: DN50	Maxflow: 800 l/min	Maxhead: 18 m	Floatswitch: NO	SKU: 110-070	RRP: £1,580.00	Our Price: £1,327.20 £1,106.00
Model: DWF 300*	Voltage: 400V	Power: 2.20 kW	Outlet: DN50	Maxflow: 900 l/min	Maxhead: 21 m	Floatswitch: NO	SKU: 110-072	RRP: £1,782.00	Our Price: £1,496.88 £1,247.40
Model: DWF Pedestal Kit	Voltage: -	Power: N/A	Outlet: DN50	Maxflow: N/A	Maxhead: N/A	Floatswitch: N/A	SKU: 115-001	RRP: £571.00	Our Price: £548.16 £456.80

Details

Ebara DWF submersible water pumps are designed to transfer wastewater and sewage containing solids up to 50mm. These high-quality submersible wastewater pumps are versatile solutions suitable for remote sewage stations for housing developments, agricultural waste, pubs, hotels, restaurants and water displays.

Thanks to the pump body’s AISI 304 Stainless Steel construction, these Ebara submersible water pumps are constructed specifically for anti-corrosion and heavy-duty applications. Carefully designed to provide the highest pump quality and efficiency, these submersible sewage pumps come with flanged connection and double mechanical seals to prevent leakage, increase service life and ensure reliability. This Ebara DWF electric submersible pump is supplied with a channel impeller which is more efficient than vortex impellers, but it needs to be considered that it is more prone to blockage. For all sewage applications, as a leading submersible pump supplier, we recommend using vortex impeller pumps due to the minimal risk of clogging and solid handling capabilities, unless the discharge head is too high or the pipe run is too long.

Available with or without a float switch for automatic operation, these submersible wastewater pumps are lightweight and easy to move and install, making them a perfect solution for many domestic, industrial and agricultural applications. There is also a model available with a cast iron spacer.

Specifications
►Maximum liquid temperature: 40°C
►Maximum immersion depth: 7 Metres
►Maximum soft solids: 50 mm
►Outlet: 2" B.S.P. Female
►Power cable: 10 Metres
►230V pumps are fitted with UK 3 pin plug

Materials
►Pump body: AISI 304 Stainless Steel
►Impeller: AISI 304 Stainless steel

*Equipped with cast iron spacer

Whisper Pumps have been suppling Ebara pumps for over 25 years, meaning we are highly experienced in all models and our team have expert product knowledge. If you are unsure on the submersible wastewater pump model you require, please contact our technical sales team today on 01777 871100 for free, expert advice.
