Ebara DW VOX Submersible Pumps With Vortex Impeller

Ebara DW VOX submersible pumps are commonly used as submersible wastewater and sewage pumps transferring fluids containing solids up to 50mm. Ebara DW VOX pumps are suitable for remote sewage stations for housing developments, agricultural waste, pubs, hotels, restaurants and water displays.

Starting at £855.12 £712.60

Grouped product items
Model Voltage Motor Max. Flow Max. Head Float Switch SKU RRP Our Price (ex VAT)
Model: DWM 75 VOX Voltage: 230V Motor: 0.55kW Maxflow: 400 l/min Maxhead: 7 m Floatswitch: NO SKU: 110-032 RRP: £1,018.00 Our Price:
£855.12 £712.60
Model: DWM 75 VOX A Voltage: 230V Motor: 0.55kW Maxflow: 400 l/min Maxhead: 7 m Floatswitch: YES SKU: 110-033 RRP: £1,057.00 Our Price:
£887.88 £739.90
Model: DWM 100 VOX Voltage: 230V Motor: 0.75kW Maxflow: 500 l/min Maxhead: 9 m Floatswitch: NO SKU: 110-036 RRP: £1,183.00 Our Price:
£993.72 £828.10
Model: DWM 100 VOX A Voltage: 230V Motor: 0.75kW Maxflow: 500 l/min Maxhead: 9 m Floatswitch: YES SKU: 110-037 RRP: £1,219.00 Our Price:
£1,023.96 £853.30
Model: DWM 150 VOX Voltage: 230V Motor: 1.10kW Maxflow: 600 l/min Maxhead: 11 m Floatswitch: NO SKU: 110-040 RRP: £1,405.00 Our Price:
£1,180.20 £983.50
Model: DWM 150 VOX A Voltage: 230V Motor: 1.10kW Maxflow: 600 l/min Maxhead: 11 m Floatswitch: YES SKU: 110-041 RRP: £1,452.00 Our Price:
£1,219.68 £1,016.40
Model: DW 75 VOX Voltage: 400V Motor: 0.55kW Maxflow: 400 l/min Maxhead: 7 m Floatswitch: NO SKU: 110-043 RRP: £1,018.00 Our Price:
£855.12 £712.60
Model: DW 100 VOX Voltage: 400V Motor: 0.75kW Maxflow: 500 l/min Maxhead: 9 m Floatswitch: NO SKU: 110-045 RRP: £1,183.00 Our Price:
£993.72 £828.10
Model: DW 150 VOX Voltage: 400V Motor: 1.10kW Maxflow: 600 l/min Maxhead: 11 m Floatswitch: NO SKU: 110-047 RRP: £1,405.00 Our Price:
£1,180.20 £983.50
Model: DW 200 VOX Voltage: 400V Motor: 1.50kW Maxflow: 700 l/min Maxhead: 14 m Floatswitch: NO SKU: 110-049 RRP: £1,526.00 Our Price:
£1,281.84 £1,068.20
Model: DW 300 VOX* Voltage: 400V Motor: 2.20kW Maxflow: 800 l/min Maxhead: 17 m Floatswitch: NO SKU: 110-051 RRP: £1,724.00 Our Price:
£1,448.16 £1,206.80

Ebara DW VOX submersible pumps are designed to transfer wastewater and sewage containing solids up to 50mm. These high-quality submersible wastewater pumps are versatile solutions suitable for remote sewage stations for housing developments, agricultural waste, pubs, hotels, restaurants and water displays.

Thanks to the pump body’s AISI 304 Stainless Steel construction, these Ebara submersible water pumps are constructed specifically for anti-corrosion and heavy-duty applications. Supplied with vortex impellers for more efficient operation, these submersible sewage pumps are reliable pumping solutions when transferring fluid with solids. Although channel impellers are more efficient than vortex impellers, they are more prone to blockage. As a leading submersible pump supplier, we recommend using vortex impeller pumps in all sewage applications due to the minimal risk of clogging and solid handling capabilities, unless the discharge head is too high, or the pipe run is too long.

These Ebara submersible pumps are supplied with double mechanical seals to enhance the robust pump design and ensure long life and reliability. Available with or without a float switch for automatic operation, these submersible wastewater pumps are lightweight and easy to move and install, making them a perfect solution for many domestic, industrial and agricultural applications.

Specifications
►Maximum liquid temperature: 40°C
►Maximum immersion depth: 7 Metres
►Maximum soft solids: 50 mm
►Outlet: 2" B.S.P. Female
►Power cable: 10 Metres
►230V pumps are fitted with UK 3 pin plug

Materials
►Pump body: AISI 304 Stainless Steel
►Impeller: AISI 304 Stainless steel

*Equipped with cast iron spacer

Whisper Pumps have been supplying Ebara pumps for over 25 years, meaning we are highly experienced in all models and our team have expert product knowledge. If you are unsure on the submersible sewage pump model you require, please contact our technical sales team today on 01777 871100 for free, expert advice.
