Speedbox Wall Mounted Pump Variable Speed Drive

The Coelbo Speedbox is as an advanced, energy saving, air cooled variable speed drive for use with most electric single stage and multistage pumps. This water pump inverter is ideal for applications including borehole/well extraction, sump emptying and general water transfer and boosting.

Grouped product items
Model	Voltage	Power	SKU	RRP	Our Price (ex VAT)
Model: SPEEDBOX 1112 MM	Voltage: 230V 1~ in - 230V 1~out	Power: Max 12A	SKU: 4439-019	RRP: £555.71	Our Price: £466.80 £389.00
Model: SPEEDBOX 1010 MT	Voltage: 230V 1~in - 230V 1~ Or 230V 3~ out	Power: Max 10A	SKU: 4439-020	RRP: £607.14	Our Price: £510.00 £425.00
Model: SPEEDBOX 1309 TT	Voltage: 400V 3~ in - 400V 3~ out	Power: Max 9A	SKU: 4439-021	RRP: £750.00	Our Price: £630.00 £525.00

Details

The main benefit of the Speedbox is that it uses a built-in inverter to control the speed of the pump motor to actual rather than maximum requirements, maintaining a constant pressure in the system as demand on the water supply fluctuates. This also provides the user with considerable energy savings over pumps without a variable speed drive and greatly extends pump life due to reducing unnecessary mechanical stress.

Commonly used as an inverter for borehole pumps, centrifugal and submersible pumps in new or retrofit installations, the Speedbox water pump variable speed drive is wall mounted for convenience and easy to install. Its integrated intelligent software allows easy and intuitive configuration of this water pump inverter through a multi-function LCD screen with warning LED lights and start/stop push buttons.

In addition to the above, the Speedbox pump controller offers dry run protection with automatic restart to prevent damage caused to the pump under low water level conditions.

Speedbox Water Pump Inverter Specifications:
►Centrifugal, submersible, well and borehole pump variable speed drive
►Constant pressure regardless of flow
►Adjustable pressure
►Dry run protection with automatic restart after dry-run shutdown
►Run three phase pumps off a single phase supply
►No remote pressure switch required
►No separate control panel required
►No water hammer
►Provides significant energy savings
►Extended pump life due to reduced mechanical stress
►Versions available in 230V and 400V

As a longstanding centrifugal, submersible and borehole pump variable speed drive supplier, Whisper Pumps are highly experienced in all models. If you are unsure on the control box you require, please contact our technical sales team today on 01777 871100 for free, expert advice
