Ebara CDX Centrifugal Pumps 400V

Ebara CDX single impeller centrifugal pumps with hydraulic components made from AISI 304 stainless steel.

Suitable for pressure boosting, water supply, treatment & irrigation, air conditioning systems and general water pumping including moderately aggressive liquids.

Grouped product items
Model Voltage Motor Inlet Outlet Max. Flow Max. Head SKU RRP Our Price (ex VAT)
Model: CDX 70/05 Voltage: 400V Motor: 0.37kW Inlet: 1-1/4" Outlet: 1" Maxflow: 90 l/min Maxhead: 21 m SKU: 111-008 RRP: £414.00 Our Price:
£289.80
Model: CDX 70/07 Voltage: 400V Motor: 0.55kW Inlet: 1-1/4" Outlet: 1" Maxflow: 80 l/min Maxhead: 28 m SKU: 111-009 RRP: £434.00 Our Price:
£303.80
Model: CDX 90/10 Voltage: 400V Motor: 0.75kW Inlet: 1-1/4" Outlet: 1" Maxflow: 110 l/min Maxhead: 31 m SKU: 111-010 RRP: £562.00 Our Price:
£393.40
Model: CDX 120/07 Voltage: 400V Motor: 0.55kW Inlet: 1-1/4" Outlet: 1" Maxflow: 180 l/min Maxhead: 21 m SKU: 111-011 RRP: £552.00 Our Price:
£386.40
Model: CDX 120/12 Voltage: 400V Motor: 0.90kW Inlet: 1-1/4" Outlet: 1" Maxflow: 160 l/min Maxhead: 30 m SKU: 111-012 RRP: £694.00 Our Price:
£485.80
Model: CDX 120/20 Voltage: 400V Motor: 1.50kW Inlet: 1-1/4" Outlet: 1" Maxflow: 160 l/min Maxhead: 38 m SKU: 111-013 RRP: £824.00 Our Price:
£576.80
Model: CDX 200/12 Voltage: 400V Motor: 0.90kW Inlet: 1-1/2" Outlet: 1" Maxflow: 250 l/min Maxhead: 21 m SKU: 111-014 RRP: £735.00 Our Price:
£514.50
Model: CDX 200/20 Voltage: 400V Motor: 1.50kW Inlet: 1-1/2" Outlet: 1" Maxflow: 250 l/min Maxhead: 31 m SKU: 111-015 RRP: £826.00 Our Price:
£578.20
Model: CDX 200/25 Voltage: 400V Motor: 1.85kW Inlet: 1-1/2" Outlet: 1" Maxflow: 250 l/min Maxhead: 38 m SKU: 111-016 RRP: £969.00 Our Price:
£678.30
Ebara CDX single impeller centrifugal pumps with hydraulic components made from AISI 304 stainless steel.

Suitable for pressure boosting, water supply, treatment & irrigation, air conditioning systems and general water pumping including moderately aggressive liquids.

This Pump is highly suitable for breweries
Over the past few years, Whisper Pumps has seen a trend to use Ebara CDX pumps for hot wort transfer in the brewing industry. This is because of the stainless steel construction and the ability to withstand liquid temperatures of up to 110°C. However, we found that customers were experiencing problems with the pumps leaking. This is not a problem encountered when pumping water so we set about finding out why this was happening. We discovered that sugars from the wort were crystallising on the faces of the mechanical shaft seal and forcing the two components apart, thus causing the seal to leak.
After some experimentation, we found a mechanical seal with a material which will still withstand the high temperature but does not allow the sugar to adhere to the mating surfaces.
We now supply the Ebara CDX pumps with the special seal fitted. We also supply the seal as a spare part for retro fitting to existing pumps and also offer a fitting service.

Specifications
►Maximum liquid temperature:
60°C for CDX 70/05, 70/07 & 90/10
90°C for CDX 120/07, 120/12, 120/20, 200/12 & 200/20
110°C & 120°C option available
►Maximum suction lift: 9 Metres

Materials
►Pump body: AISI 304 Stainless Steel
►Impeller: AISI 304 Stainless Steel
►Shaft seal: Carbon/Ceramic/NBR
